全自動魚型KF94口罩機? ?Automatic fish mask machine

AMM-1-1F

設備技術規格書? ?Technical specification of equipment

一、全自動魚型KF94口罩機基本介紹Basic introduction

全自動kf94魚型口罩機：秦泰盛公司依據客戶需求,通過PLC編程控制，通過自動送料，壓紋、對折、切邊，翻轉，焊接耳帶等工藝一次成型，成功研發設計出全新的全自動魚型口罩機,本機具有自動化程度高，操作簡單，更人性化的特點。

Fully automatic fish mask machine: According to customer needs, Qin-Tech is controlled by PLC programming, through automatic feeding, embossing, folding, trimming, flipping, welding ear straps and other processes at one time, successfully developed and designed a new automatic fish-shaped mask machine High degree, simple operation and more user-friendly features.

二、全自動魚型KF94口罩機設備技術參數 Technical Parameters

型號：AMM-1-1F（一拖一） Model: AMM-1-1F (one drag one)

材料：兩層無紡布兩層熔噴布

Material: 3-4 ply of non-woven fabric

電壓：AC 220V,50HZ

Voltage: AC 220V, 50HZ

重量：1450KG

Weight: 1450KG

外觀尺寸：6150*1950*4680

料架:1700（L）x600(W)1780(H) ; 重量：310kg

打片機:2600（L）x650(W)1300(H) ;? 重量：670kg

耳帶焊接: 1850（L）x700(W)1600(H) ;重量：470kg??

Size:

Feeder: 1700（L）x600(W)1780(H); Weight:310kg

Folding and welding machine: 2600（L）x650(W)1300(H);? Weight:670kg??

Ear belt machine: 1850（L）x700(W)1600(H); Weight:470kg

效率： 70pcs/min（±10％）

Efficiency: 70pcs/min（±10％）

產品規格：可依據客戶要求進行定制

Product specifications: can be customized according to customer requirement.

適用行業：一次性醫療防護用品

Applicable industries: disposable medical protective equipment

三、全自動魚型KF94口罩機產品特性Product Features

整機由料架部分，上鼻線部分，外形熔接部分，折疊成型，外形切刀部分，焊接耳帶部分，成品輸出組成，采用伺服電機，超聲波焊接技術完成生產。

The whole machine is composed of the material rack part, the upper nose line part, the shape welding part, the folding forming, the shape cutter part, the welding ear belt part, and the finished product output. The servo motor and ultrasonic welding technology are used to complete the production.

1.料架部分：自動送料，剎車配合控制器，保證材料張力。

1. Material rack part: automatic feeding, brake cooperate with controller to ensure material tension.

2.鼻梁條部分：采用調速電機控制自動輸送鼻梁條配合齒模超聲波焊接

2. Nose bridge section: the cylinder is welded by ultrasonic wave, and the nose bridge is automatically conveyed

3.外形熔接部分：定制齒模配合超聲波，完成紋路焊接。

3. Shape welding part: the mold is matched with ultrasonic wave to complete the texture welding.

4.折疊成型：折疊布料

4. Folding: folding fabric

5.外形切刀部分：定制切刀，滾切成型。

5. Shape cutter part: customized cutter, roll-cutting forming.

6.翻轉部分：可根據口罩焊接方式實現翻轉。

6. Flip part: turn the mask over.

7.耳帶焊接：采用全伺服控制效率高每分鐘可高達70PCS（±10％）后期維護成本低，配合超聲波完成耳帶線焊接。

7. Adopt full servo control, high efficiency, up to 70PCS per minute (±10%), low maintenance cost in later stage, and complete the welding of ear strap line with ultrasonic.

8.成品輸出：口罩成品輸出，收集。

8. Output of finished products: output and collection of finished masks.

四、原材料規格（建議）：

由外至內（材料幅寬260mm）

層SS級50克無紡布 外層

層99級25克熔噴布

第三層99級25克熔噴布

第四層SS級25克無紡布 內層
